Camera

Image Sensor

1/2.8" CMOS

Effective Pixels

1945(H)×1097(V), 2.1MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1.3s~1/30000s

NTSC: 1s~1/30000s

Minimum Illumination

0.005Lux/F1.4, 30IRE, 0Lux IR on

S/N Ratio

More than 65dB

IR Distance

Up to 100m (328feet)

IR On/Off Control

Auto / Manual

IR LEDs

4

Lens

Lens Type

Motorized lens / Auto iris

Mount Type

Board-in

Focal Length

2.7-12mm

Max Aperture

F1.4

Angle of View

H: 95°~36°

Focus Control

Auto / Manual

Close Focus Distance

300mm

11.81''

Pan / Tilt / Rotation

Pan/Tilt/Rotation

Pan: 0° ~ 360°

Tilt: 0° ~ 90°

Rotation: 0° ~ 360°

Video

Resolution

1080P (1920×1080)

Frame Rate

25/30fps@1080P, 25/30/50/60fps@720P

Video Output

1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output

CVBS tester out

Day/Night

Auto (ICR) / Manual

OSD Menu

Multi-language

BLC Mode

BLC / HLC / WDR

WDR

120dB

Gain Control

AGC

Noise Reduction

2D / 3D

White Balance

Auto / Manual

Smart IR

Auto / Manual

DORI Distance

Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.

DORI

Definition

Distance

Wide

Tele

Detect

25px/m (8px/ft)

48m(159ft)

133m(437ft)

Observe

63px/m (19px/ft)

19m(64ft)

53m(175ft)

Recognize

125px/m (38px/ft)

10m(32ft)

27m(87ft)

Identify

250px/m (76px/ft)

5m(17ft)

13m(44ft)

Certifications

Certifications

CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Interface

1-channel audio in

Alarm Interface

1-channel alarm in & 1-channel alarm out

Eelectrical

Power Supply

AC 24V±25% / DC 12V±25%

Power Consumption

Max 22.9W (12V DC, IR & heater on)

Environmental

Operating Conditions

-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

* Start up should be done at above -40°C (-40°F)

Storage Conditions

-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

Ingress Protection & Vandal Resistance

IP67 & IK10

Construction

Casing

Aluminium

Dimensions

273.2mm×95.0mm×95.0mm (10.76"×3.74"×3.74")

Net Weight

1.16kg (2.56lb)

Gross Weight

1.52kg (3.35lb)
